Forced Air Furnaces


Forced Air Furnaces have long been the "Go To" method of heating homes and shops. Our Hyprotherm forced air outdoor wooden furnaces are cost effective and deliver consistently lower annual energy costs. Our high quality wood furnaces give you a sustainable source of energy that is long term and needs no hard maintenance. With many options to suit your specific needs, our Outdoor Furnaces are sure to provide a clean and efficient means of heating your space.

HYPROTHERM FRONT LOADING RESIDENTIAL COAL OR WOOD FORCED AIR


The Hyprotherm, Front Loading, Residential Forced Air series is a front loading furnace with a larger firebox then any other furnace in its class. These coal or wood furnaces feature fireboxes that are 1/4” thick. The air jacket bottom is also 1/4” thick with the sides and top being 1/8”. All of these front loading furnaces come with large 24” x 24” fuel fill doors and removable ash pans to make ash removal simple. They have round steel grates and each furnace is pre wired with only one connection to a power supply and one connection to your home thermostat necessary, making them basically plug and play.

    Hyprotherm FLFA-1000
  • Air Jacket; 1/8”
  • Firebox Capacity; 16 cubic feet
  • Firebox Dimensions; 1/4” thick x 28L” x 30”W x 34”H
  • Fuel Door; 24” x 24”
  • Grate System; Round Steel
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 91,000
  • Heatable Area; 3,500 sq ft
  • Retail: $5,197
    Hyprotherm FLFA-2000
  • Air Jacket; 1/8”
  • Firebox Capacity; 24 cubic feet
  • Firebox Dimensions; 1/4” thick x 42”L x 30”W x 34”H
  • Fuel Door; 24” x 24”
  • Grate System; Round Steel
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 135,000
  • Heatable Area; 5,500 sq ft
  • Retail: $6,227
    Hyprotherm FLFA-3000
  • Air Jacket; 1/8”
  • Firebox Capacity; 33 cubic feet
  • Firebox Dimensions; 1/4” thick x 56”L x 30”W x 34”H
  • Fuel Door; 24” x 24”
  • Grate System; Round Steel
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 165,000
  • Heatable Area; 6,875 sq ft
  • Retail: $6,887
    Hyprotherm FLFA-4000
  • Air Jacket; 1/8”
  • Firebox Capacity; 41 cubic feet
  • Firebox Dimensions; 1/4” thick x 69”L x 30”W x 34”H
  • Fuel Door; 24” x 24”
  • Grate System; Round Steel
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 205,000
  • Heatable Area; 8,500 sq ft
  • Retail: $8,467

HYPROTHERM “FRONT LOADING L-TW RESIDENTIAL” OUTDOOR FURNACE FORCED AIR (COAL OR WOOD)

The Hyprotherm , Front Loading, L Series Forced Air series is a front loading furnace with a round firebox based on the old style hydronic furnace. These coal/wood furnaces feature fireboxes that are 3/8” thick with ¼” end caps and the air jacket is 1/8” thick. All of these front loading furnaces come with large 24” x 24” fuel fill doors and have round steel grates. A 6” x 14” door provides access to the ash compartment below the fuel door.

    Hyprotherm L-TW-1000
  • Air Jacket; 1/8”
  • Firebox Capacity; 12.81 cubic feet
  • Firebox Dimensions; 3/8” thick x 28L” x 36” tube
  • Fuel Door; 19" x 19"
  • Grate System; Round Steel
  • Ash Cleanout: No Removable Ash Pan
  • BTUs; 91,000
  • Heatable Area; 3,500 sq ft
  • Retail: $5,204
    Hyprotherm L-TW-2000
  • Air Jacket; 1/8”
  • Firebox Capacity; 19.33 cubic feet
  • Firebox Dimensions; 3/8" thick x 42" x 36" tube
  • Fuel Door; 19" x 19"
  • Grate System; Round Steel
  • Ash Cleanout: No Removable Ash Pan
  • BTUs; 91,000
  • Heatable Area; 5,500 sq ft
  • Retail: $5,962
    Hyprotherm L-TW-3000
  • Air Jacket; 1/8”
  • Firebox Capacity; 25.86 cubic feet
  • Firebox Dimensions; 3/8” thick x 56”L x 36” tube
  • Fuel Door; 19" x 19"
  • Grate System; Round Steel
  • Ash Cleanout: No Removable Ash Pan
  • BTUs; 165,000
  • Heatable Area; 6,875 sq ft
  • Retail: $6,475
    Hyprotherm L-TW-4000
  • Air Jacket; 1/8”
  • Firebox Capacity; 31.92 cubic feet
  • Firebox Dimensions; 3/8” thick x 69”L x 36” tube
  • Fuel Door; 19" x 19"
  • Grate System; Round Steel
  • Ash Cleanout: No Removable Ash Pan
  • BTUs; 205,000
  • Heatable Area; 8,500 sq ft
  • Retail: $8,214

HYPROTHERM “TOP LOADING RESIDENTIAL” OUTDOOR FURNACE, FORCED AIR (COAL OR WOOD)

Midwest Outdoor Furnace - Steinacher Sales 21690 Richey Hollow Rd. Jerseyville, IL 62052

The Hyprotherm, Top Loading, Residential (coal or wood)Forced Air series is a new concept based on our Chest Loading series. All of these top loading furnaces come with easy opening, gas spring assisted fuel doors. They have 3/8” thick fireboxes which set vertically inside the air jacket. This allows for the Top Loading fuel door and an economical complete burning fire. The air jacket is 1/8” steel top, bottom and sides. They have cast iron shaker grates and are designed to burn coal or wood. They have removable ash pans to make ash removal simple. Each furnace is pre wired with only one connection to a power supply and one connection to your home thermostat necessary, making them basically plug and play simple.

    Hyprotherm TLFA-1500
  • Air Jacket; 1/8”
  • Firebox Capacity; 10.1 cubic feet
  • Firebox Dimensions; 3/8” thick x 27” x 28.25”
  • Fuel Door; 24” x 24”
  • Grate System; Shaker
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 138,900
  • Heatable Area; 1,500 sq ft
  • Retail: $5,795
    Hyprotherm TLFA-3500
  • Air Jacket; 1/8”
  • Firebox Capacity; 12.48 cubic feet
  • Firebox Dimensions; 3/8” thick x 28” x 28.25”
  • Fuel Door; 24” x 24”
  • Grate System; Shaker
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 145,600
  • Heatable Area; 3,500 sq ft
  • Retail: $7,244
    Hyprotherm TLFA-4500
  • Air Jacket; 1/8”
  • Firebox Capacity; 15.31 cubic feet
  • Firebox Dimensions; 3/8” thick x 31” x 28.25”
  • Fuel Door; 24” x 24”
  • Grate System; Shaker
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 203,900
  • Heatable Area; 4,500 sq ft
  • Retail: $8,014
    Hyprotherm TLFA-5500
  • Air Jacket; 1/8”
  • Firebox Capacity; 18.42 cubic feet
  • Firebox Dimensions; 3/8” thick x 34” x 28.25”
  • Fuel Door; 24” x 24”
  • Grate System; Shaker
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 255,400
  • Heatable Area; 5,500 sq ft
  • Retail: $8,715
    Hyprotherm TLFA-6800
  • Air Jacket; 1/8”
  • Firebox Capacity; 21.88 cubic feet
  • Firebox Dimensions; 3/8” thick x 37” x 28.25”
  • Fuel Door; 24” x 24”
  • Grate System; Shaker
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 308,100
  • Heatable Area; 6,800 sq ft
  • Retail: $9,541
    Hyprotherm TLFA-8500
  • Air Jacket; 1/8”
  • Firebox Capacity; 27 cubic feet
  • Firebox Dimensions; 3/8” thick x 41” x 28.25”
  • Fuel Door; 24” x 24”
  • Grate System; Shaker
  • Ash Cleanout: Removable Ash Pan
  • BTUs; 339,500
  • Heatable Area; 8,500 sq ft
  • Retail: $10,846
